Garrett Guide Hand-held Metal Detector

Garrett has been the Metal Detector name to trust for 40 years, but they never rest on their laurels and the exciting new, super sensitive, “Garrett Guide” Hand-held Metal Detector Body Scanner is further evidence of their commitment to continuous development.

Building on the success of the Garrett Super Scanner V model, which has been the trusted go-to hand held Detector Wand by police, governments, armed services, schools and security professionals worldwide, the Garrett Guide, is easy to use and offers 21st century technology for optimum performance and operational convenience.

Key Features and Benefits,

Ultra Sensitive Response

Designed to detect all ferrous, non-ferrous and stainless steel, weapons, contraband and other metallic objects.

7 user selectable sensitivity levels

Making the unit suitable for all security applications.

Water Resistant

Manufactured to meet IEC 529 IP65 standards, for reliable operation in both indoor or outdoor environments, whatever the weather.

Choice of feedback indicators

Simple switch operated choice of detection alert types, including; Audio, Vibro and LED illuminator indicators, to cater for use in any environment.
Vibro feedback for instance, is great for the operator, when using the scanner in noisy environments or where discreet feedback is preferred.

Rugged Construction and Tactile Grip

The tactile rubber grip handle combined with the light weight of the unit, is designed to minimise operator fatigue when using the unit for extended periods, while the rugged construction offers powerful durability to meet Military Specification Standards for Drop Test.

Rechargeable 2.5 Ahr Battery

The rechargeable internal Lithium Ion battery eliminates the environmental damage arising from the disposal of standard single use batteries.

The USB-C charging point in the base of the handle allows charging of the internal battery via the purpose designed charging cradle, or direct from a suitable plug-top style USB charger. A fully charged internal battery offers up to 125 hours operational use, while fully recharging it will take up to 5 hours.

Auto Adjustment

No fiddly ongoing adjustments required with this unit, as once you have selected the sensitivity level required with the Sensitivity Switch the unit is fully automatic.

For operational convenience and practicality, conveniently located switches on the unit offer temporary override facilities to eliminate interference from other units, or to temporarily reduce the units sensitivity when scanning at floor level where rebar construction could be encountered.

Garrett Guide Users,

The Garrett Guide is a perfect choice for use at Schools, Sports and Event Stadiums & Venues, Court Houses, Prisons, Hospitals, Public Buildings, Nightclubs, …and just about anywhere else that people need to be scanned quickly and efficiently for concealed weapons or other metallic items.

Specifications,

Three-colour LED Indication  Green LED = On

                                          White LED = Status / Sensitivity

                                          Red LED = Alarm

Operating Temperature        -4 deg F (-20C) to 140 deg F (60C)

Humidity                            100%

Audio Frequency                 ~ 2 kHz

Detection Frequency           ~ 55 kHz

Voltage                              3.8 Vdc

Current                              15 mA typical

Tuning                               Automatic

Width                                9 cm (3.375”)

Thickness                          3 cm (1.125”)

Length                              41 cm (16”)

Total Weight                      0.5kg (1 lb)

Environmental                   IP 65 rating

Battery Requirements        Lithium Ion 3.8V 2.5 Ahr (included)
                                        Capacity 125 hours

Warranty,

The unit comes with a Manufacturers 3 Year Limited Parts/Labour Warranty.

Options and Accessories

The Garrett Guide product is available with various options and accessories;

- as an individual unit with a USB charging cable,

- a Garrett Guide Unit with Charging Base & Charger
  (up to 5 bases can be stacked together and powered by a single 15W charger),

- Checkpoint Multi Pack - which includes 5 stacked Charger Bases with one 15W Charger,
  complete with 5 Garrett Guide detectors,

- Charging Base only (does not include charger, cable, or Garrett Guide scanner unit)

- USB-A to USB-C charging Cable

- 15W USB Charger

- Wrist Strap
